Magnum 500-Series Switching Hubs
Installation and User Guide (08/98)
GARRETT
16
Figure 3.1.3 : Magnum 528 mounted on E-stand
3.2
Powering the Magnum 500-Series Switch
Magnum 500-Series Switching Hubs incorporate an internal universal power
supply, and have a recessed male IEC connector for the AC power cord at the right-rear.
A six-foot 115 VAC 60 Hz standard power cord is supplied with each unit shipped
within the United States and Canada.
Figure 3.2: Magnum 500-Series AC power connector
The Magnum 500’s auto-ranging power supply supports installation
environments where the AC voltage is from 90 to 260 volts with a power input frequency
between 47 and 63 Hz. The unit will consume just under 10 watts of power typically.
When connecting the Ethernet cabling, there is no need to power down the
unit. Individual segments can be connected or disconnected without concern for AC
power-related problems or damage to the unit.
Screw holes
Rectangular
cut-out
(Air Vent)
M
a
g
num
5
2
8
Sw
it
c
h
in
g H
u
b
GARRE
T
T
1
2
3
4
5
6
7
8
LI
N
K
RX
UP
L
IN
K
AU
T
O
1
0
PW
R
LI
N
K
RX
1
2
10
GARRE
TT
115-230V~ 50/60 Hz
