Magnum 500-Series Switching Hubs Installation and User Guide (08/98)
GARRETT
2
Fiber Optic Interface
100Mb/s Single-mode Port
Optical
Typical Worst
Wavelength 1300nm -----
Transmitter output power -11.5dBm -15.5dBm
Receiver sensitivity -32dBm ----
Fiber Optic cable type 9/125
µ
m single-mode
Saturation -8dBm
Max. Distance 15Km full-duplex (412m HDX, PDV limit)
100Mb/s Multi-mode Port
Optical
Typical Worst
Wavelength 1300nm -----
Transmitter output power -16.5dBm -19.5dBm
Receiver sensitivity -23.5dBm -32.5dBm
Fiber Optic cable type 62.5/125
µ
m multi-mode
Saturation -14dBm
Max. Distance 2Km full-duplex (412m HDX, PDV limit)
LEDs:
PWR (AC power), LK/RX (per-port Link & Receive),
FDX (per-port full / half-duplex mode for 10Mb ports)
For Model 528 Fast Ethernet copper ports only:
AUTO (Auto-negotiation operation), per-port, 100 (ON for 100Mb/s
speed), 10 (ON for 10Mb/s speed), F/H (Full- or Half-Duplex, ON for
full-duplex, OFF for half-duplex). No AUTO for Model 528F Fiber ports
Operating Environment
Ambient Temperature: 32 ° to 120 ° F (0 ° to 50 ° C)
Storage Temperature: -20
°
to 60
°
C
Ambient Relative Humidity: 10% to 95% (non-condensing)
Packaging
Enclosure: High strength metal. Suitable for wiring closet shelf,
desktop, or vertical / wall mounting (brackets included)
Dimensions: 9.55 in D x 8.5 in W x 1.3 in H (24 cm x 22cm x 3.3 cm)
Weight:
2.5 lb. (1.15 Kg)
Cooling method: Fan cooled, @ 9 cfm
Power Supply (Internal)
AC Power Connector: IEC-type, male recessed, rear of chassis
Input Voltage: 90 to 260 VAC (auto-ranging)
Input Frequency: 47 to 63 Hz (auto-ranging)
Power Consumption: 10 watts typical, 20 watts P.S. rating
Agency Approvals
UL listed (UL1950), cUL, CE
Emissions meet FCC Part 15 Class A
Warranty
Three years, return to factory Made in USA
