25
APPENDIX A BLOWER PERFORMANCE TABLES
DIRECT DRIVE
CPG036 DOWN SHOT AND HORIZONTAL
SPEED TAP
EXTERNAL STATIC
PRESSU RE (ESP)
i n w.c.
STANDARD
CFM
AMPS WATTS RPM
0. 10 1313 1.68 356 748
0. 20 1247 1.63 344 786
0. 30 1178 1.59 334 832
0. 40 1094 1.55 324 869
0. 50 1002 1.50 312 913
0. 60 919 1.45 296 940
0. 10 1471 2.11 454 830
0. 20 1400 2.06 440 863
0. 30 1354 2.02 432 896
0. 40 1271 1.95 416 929
0. 50 1188 1.90 398 957
0. 60 1083 1.82 378 984
0. 70 955 1.74 356 1012
0. 30 1470 2.37 510 935
0. 40 1390 2.31 492 957
0. 50 1310 2.25 476 978
0. 60 1206 2.17 454 1000
0. 70 1098 2.09 436 1023
0. 80 966 1.99 412 1045
SPEED TAP
EXTERNAL STATIC
PRESSU RE (ESP)
i n w.c.
STANDARD
CFM
AMPS WATTS RPM
0. 10 1293 1.72 364 715
0. 20 1235 1.67 354 759
0. 30 1173 1.62 342 803
0. 40 1124 1.58 330 841
0. 50 1056 1.54 316 880
0. 60 978 1.47 298 913
0. 10 1500 2.13 462 808
0. 20 1434 2.10 448 838
0. 30 1381 2.04 436 869
0. 40 1318 2.00 424 902
0. 50 1238 1.94 406 929
0. 60 1163 1.88 392 951
0. 70 1055 1.80 370 990
0. 80 936 1.72 350 1017
0. 40 1441 2.35 504 940
0. 50 1355 2.28 484 962
0. 60 1264 2.21 468 989
0. 70 1157 2.13 446 1012
0. 80 1027 2.03 418 1034
0. 90 840 1.90 388 1067
NOTES:
3 Ton models are shipped from the factory with sp eed tap set on LOW.
Tab les represent dry coil without filter, to compensate for filter add 0.08" to measured E.S.P. SCFM
correction for wet coil = 4 %.
CPG036 DIRECT DRIVE HORIZONTAL
LOW
MED
HIGH
HIGH
CPG036 DIRECT DRIVE DOWN SHOT
LOW
MED
