FRONT CASTER ASSEMBLY - 73
FRONT CASTER ASSEMBLY
NOTES
Ref. No.
Part No.
Description
Qty.
Remarks
1
200334
YOKE
1
CASTER
2
TCU14490
ROUND RETAINER
2
3
AA21840
BALL BEARING
2
4
TCU13871
SPACER
1
5
TCA13769
TIRE AND WHEEL ASSEMBLY
1
13" CASTER
6
19M7978
CAP SCREW
1
7
14M7276
NUT
1
M16
8
TCU13454
SPACER
1
9
E14625
SEAL
1
10
JD8933
BEARING CONE
2
11
145553
BEARING CUP
2
12
24H1801
WASHER
1
13
11M7083
COTTER PIN
1
3.200 X 50 MM
14
A12188
LOCK NUT
1
15
M35582
DUST CAP
1
16
JD7844
LUBRICATION FITTING
1
17
TCU13604
RIM
1
13"
18
TCU15970
TIRE
1
13 X 5.00-5, 4 PLY
19
AM30795
TIRE VALVE STEM
1
