FRAME ASSEMBLY - 71
FRAME ASSEMBLY
* NOTE: See authorized servicing engine dealer for engines and engine related service items. Always reference the
engine model number when ordering parts.
NOTES
Ref. No.
Part No.
Description
Qty.
Remarks
1
200886
FRAME
1
2
14M7396
LOCK NUT
1
M8
3
E53830
CLAMP
1
4
GDU10222
PLATE
1
5
03M7199
BOLT
4
M12 X 35
6
H137329
LOCK NUT
8
7
03M7197
BOLT
4
M12 X 25
8
JD7844
LUBRICATION FITTING
2
9
200329
PLATFORM
2
10
135139
LOCK NUT
2
11
964022
LOCK NUT
2
12
GDU10165
FENDER
1
LH
13
GDU10164
FENDER
1
RH
14
03M7017
BOLT
7
M10 X 25
15
03M7085
BOLT
1
M10 X 30
16
14M7518
FLANGE NUT
21
M10
17
19M7865
SCREW
3
M8 X 16
18
200352
BUMPER
1
KOHLER/BRIGGS ENGINE
200845
BUMPER
1
KAWASAKI
19
GDU10285
PLATE
2
20
GDU10184
BRACKET
1
21
GDU10170
BRACKET
1
22
180658
TRACTION TAPE
2
