CONSOLE AND CONTROL ASSEMBLY - 63
CONSOLE AND CONTROL ASSEMBLY
Ref. No. Part No. Description Qty. Remarks
1 GDA10083 CONSOLE 1
2 19M7785 SCREW 5 M10 X 25
3 14M7400 LOCK NUT 7 M10
4 D14133 CAP SCREW 2
5 N10217 LOCK NUT 2
6 GDU10046 BRACKET 1 RH SEAT PLATE
7 GDU10045 BRACKET 1 LH SEAT PLATE
8 19M7867 SCREW 4 M8 X 25
9 14M7396 LOCK NUT 16 M8
10 GDA10097 PIVOT 1 LH CONTROL
11 GDA10098 PIVOT 1
12 M44508 BUSHING 4
13 200397 THRUST WASHER 4
14 GDU10253 ARM 2
15 AA34134 BALL BEARING 2
16 24M7388 WASHER 6 10 X 16 X 1 MM
17 03M7195 BOLT 2 M10 X 45
18 M85516 LOCK NUT 2
19 19H1936 CAP SCREW 2 3/8" X 3/4"
20 GX10707 EXTENSION SPRING 2
21 D14236 SCREW 2
22 14H778 NUT 4 .190"
23 TCA13253 PIVOT 1
24 03M7184 BOLT 2 M8 X 20
25 M78480 TIE BAND 1
26 GDA10081 CONTROL LEVER 1 LH
27 GDA10080 CONTROL LEVER 1 RH
28 D18093 GRIP 2
29 03M7184 BOLT 8 M8 X 20
30 19H3693 SCREW 2 3/8" X 1 1/4"
31 TCU17400 ROD 2 CONTROL
32 D33002 SWIVEL 2 ADJUSTER
33 24M7106 WASHER 8 10 X 18 X 2.500 MM
34 M88183 LOCKING RING 2
35 TCA15322 GAS OPERATED CYLINDER 2
36 GDA10136 BRACKET 1
37 J16931 PIN 4
38 200591 ACCELERATOR 1
39 D38146 CABLE 1 CHOKE
40 14H1080 NUT 1 3/8"
