OVER THE LAP CONTROL ASSEMBLY
Ref. No. Part No. Description Qty. Remarks
1 TCU14989 TUBE 2
2 M131171 GRIP 2
3 GDU10047 STRAP 2
4 19M8320 SCREW 4 M10 X 45
5 14M7518 FLANGE NUT 4 M10
6 03M7195 BOLT 2 M10 X 45
7 M85516 LOCK NUT 2 M10
8 TCU13271 ARM 2
9 GDU10275 COVER 1
10 37M7059 SCREW 3 M5 X 12
KIT NUMBER GDB10035
