SS-PCB50
9
P
RODUCT
S
PECIFICATIONS
INDOOR
AIR
CONDENSER AIR TEMPERATURE
23.9°C 29.4°C 35.0°C 40.6°C 46.1°C
L/S WB
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
2246
22.2 64.17 29.53 16.42 60.17 28.00 18.63 56.17 26.48 20.83 52.17 24.95 23.04 48.17 23.43 25.25
19.4 59.19 35.59 15.36 55.27 34.49 17.50 51.35 33.39 19.63 47.42 32.29 21.76 43.50 31.20 23.89
16.7 53.86 43.83 14.67 51.14 41.88 16.64 48.42 39.93 18.61 45.69 37.99 20.59 42.97 36.04 22.56
13.9 52.05 47.66 14.10 49.01 44.75 16.15 45.97 41.85 18.21 42.93 38.94 20.27 39.90 36.04 22.33
2643
22.2 66.90 32.71 16.97 62.61 31.14 19.21 58.31 29.56 21.45 54.01 27.99 23.68 49.71 26.42 25.92
19.4 61.40 41.82 15.87 57.44 40.10 18.05 53.48 38.39 20.22 49.53 36.68 22.40 45.57 34.96 24.57
16.7 56.02 51.22 14.77 52.89 48.26 17.00 49.76 45.30 19.23 46.63 42.34 21.46 43.50 39.38 23.68
13.9 56.02 51.22 14.77 52.89 48.26 17.00 49.76 45.30 19.23 46.63 42.34 21.46 43.50 39.38 23.68
3039
22.2 68.54 35.09 17.33 64.22 33.66 19.59 59.89 32.22 21.85 55.57 30.78 24.11 51.24 29.34 26.37
19.4 63.03 47.01 16.27 59.05 45.02 18.46 55.07 43.02 20.64 51.09 41.02 22.83 47.11 39.03 25.01
16.7 59.20 54.38 15.49 55.79 51.20 17.76 52.38 48.02 20.03 48.98 44.84 22.30 45.57 41.66 24.57
13.9 59.20 54.38 15.49 55.79 51.20 17.76 52.38 48.02 20.03 48.98 44.84 22.30 45.57 41.66 24.57
C
OOLING
C
APACITY
D
ATA
(
CONT
.)
PCB120-5 (SI U
NITS
)
INDOOR
AIR
CONDENSER AIR TEMPERATURE
23.9°C 29.4°C 35.0°C 40.6°C 46.1°C
L/S WB
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
Total
Cap.
Sens
Cap.
Kw
1605
22.2 43.67 21.02 9.95 41.04 19.52 11.27 38.41 18.03 12.59 35.78 16.54 13.91 33.15 15.04 15.23
19.4 40.29 25.44 9.31 37.70 24.09 10.59 35.11 22.74 11.86 32.52 21.38 13.14 29.93 20.03 14.41
16.7 36.65 31.24 8.89 34.88 29.22 10.07 33.11 27.19 11.25 31.34 25.17 12.43 29.57 23.14 13.61
13.9 35.42 33.85 8.54 33.43 31.17 9.78 31.44 28.49 11.01 29.45 25.82 12.24 27.45 23.14 13.47
1888
22.2 45.54 23.30 10.28 42.71 21.72 11.62 39.87 20.13 12.96 37.04 18.55 14.30 34.20 16.96 15.64
19.4 41.79 29.83 9.62 39.18 27.99 10.92 36.57 26.14 12.22 33.97 24.29 13.52 31.36 22.45 14.82
16.7 38.12 36.41 8.95 36.07 33.63 10.29 34.03 30.85 11.62 31.98 28.07 12.95 29.93 25.29 14.29
13.9 38.12 36.41 8.95 36.07 33.63 10.29 34.03 30.85 11.62 31.98 28.07 12.95 29.93 25.29 14.29
2170
22.2 46.65 25.03 10.50 43.81 23.49 11.85 40.96 21.94 13.20 38.11 20.39 14.55 35.26 18.84 15.90
19.4 42.90 33.53 9.86 40.28 31.41 11.17 37.66 29.29 12.48 35.04 27.18 13.78 32.41 25.06 15.09
16.7 40.29 38.65 9.39 38.05 35.67 10.75 35.82 32.70 12.11 33.59 29.72 13.46 31.36 26.75 14.82
13.9 40.29 38.65 9.39 38.05 35.67 10.75 35.82 32.70 12.11 33.59 29.72 13.46 31.36 26.75 14.82
PCB120-5 (E
NGLISH
U
NITS
)
Sensible heat capacities shown are based on 26.7°C DB entering air at the evaporator coil. For sensible heat capacities at other
than 26.7°C DB, deduct 44.32 W per 47 L/S of evaporator coil air for each degree below 26.7°C, or add 44.32 W per 47 L/S of
evaporator coil air per degree above 26.7°C.
INDOOR
AIR
CONDENSER AIR TEMPERATURE
75°F 85°F 95°F 105°F 115°F
SCFM WB
Total
Kbtuh
Sens
Kbtuh
Kw
Total
Kbtuh
Sens
Kbtuh
Kw
Total
Kbtuh
Sens
Kbtuh
Kw
Total
Kbtuh
Sens
Kbtuh
Kw
Total
Kbtuh
Sens
Kbtuh
Kw
3400
72 149.0 71.7 9.95 140.0 66.6 11.27 131.1 61.5 12.59 122.1 56.4 13.91 113.1 51.3 15.23
67 137.5 86.8 9.31 128.6 82.2 10.59 119.8 77.6 11.86 111.0 73.0 13.14 102.1 68.4 14.41
62 125.1 106.6 8.89 119.0 99.7 10.07 113.0 92.8 11.25 106.9 85.9 12.43 100.9 79.0 13.61
57 120.9 115.5 8.54 114.1 106.4 9.78 107.3 97.2 11.01 100.5 88.1 12.24 93.7 79.0 13.47
4000
72 155.4 79.5 10.28 145.7 74.1 11.62 136.1 68.7 12.96 126.4 63.3 14.30 116.7 57.9 15.64
67 142.6 101.8 9.62 133.7 95.5 10.92 124.8 89.2 12.22 115.9 82.9 13.52 107.0 76.6 14.82
62 130.1 124.2 8.95 123.1 114.7 10.29 116.1 105.3 11.62 109.1 95.8 12.95 102.1 86.3 14.29
57 130.1 124.2 8.95 123.1 114.7 10.29 116.1 105.3 11.62 109.1 95.8 12.95 102.1 86.3 14.29
4600
72 159.2 85.4 10.50 149.5 80.1 11.85 139.8 74.9 13.20 130.0 69.6 14.55 120.3 64.3 15.90
67 146.4 114.4 9.86 137.5 107.2 11.17 128.5 100.0 12.48 119.6 92.7 13.78 110.6 85.5 15.09
62 137.5 131.9 9.39 129.9 121.7 10.75 122.2 111.6 12.11 114.6 101.4 13.46 107.0 91.3 14.82
57 137.5 131.9 9.39 129.9 121.7 10.75 122.2 111.6 12.11 114.6 101.4 13.46 107.0 91.3 14.82
Sensible heat capacities shown are based on 80°F DB entering air at the evaporator coil. For sensible heat capacities at other
than 80°F DB, deduct 84 BTU/h per 100 CFM of evaporator coil air for each degree below 80°F, or add 84 BTU/h per 100 CFM of
evaporator coil air per degree above 80°F.
PCB180-5 (SI U
NITS
)
Sensible heat capacities shown are based on 26.7°C DB entering air at the evaporator coil. For sensible heat capacities at other
than 26.7°C DB, deduct 44.32 W per 47 L/S of evaporator coil air for each degree below 26.7°C, or add 44.32 W per 47 L/S of
evaporator coil air per degree above 26.7°C.
