Page 2
2
SS-PCB50
P
RODUCT
S
PECIFICATIONS
S
PECIFICATIONS
PCB090-5
PCB120-5
PCB180-5
Total Cooling - BTU/h (kW)
88,400 (25.9)
118,600 (34.8)
172,000 (50.4)
Sensible Cooling - BTU/h¹ (kW)
67,100 (19.7)
89,200 (26.1)
131,000 (38.4)
EER²
8.9
9.7
8.5
Indoor Blower (Qty.)
2
2
2
Type
Belt
Belt
Belt
Size - D x W (mm)
12 x 12 (305 x 305)
12 x 15 (305 x 381)
12 x 15 (305 x 381)
Motor Horsepower (kW)
2 (1.49)
3 (2.24)
5 (3.73)
Indoor CFM Nominal (L/S)
3000 (1416)
4000 (1888)
5600 (2643)
Evaporator Coil (Qty.)
1
1
1
Face Area - Ft.² (m²)
9.3 (0.86)
14.0 (1.3)
14.0 (1.3)
Rows/FPI (FPM)
3/16 (630)
3/16 (630)
3/16 (630)
Tube Diameter (mm)/Material
3/8” (9.5)/Copper
3/8” (9.5)/Copper
3/8” (9.5)/Copper
Filter Size/Qty. (mm)
25” x 25” x 2”
(635 x 635 x 8.51)/3
16” x 25” x 2”
(406 x 635 x 51)/3
20” x 25” x 2”
(508 x 635 x 51)/3
16” x 25” x 2”
(406 x 635 x 51)/3
20” x 25” x 2”
(508 x 635 x 51)/3
Outdoor Fan (Qty.)
2
2
4
Fan Diameter (mm)
24” (610)
24” (610)
22” (559)
Motor Horsepower (kW)
1/2 (0.37)
1/2 (0.37)
1/2 (0.37)
Outdoor CFM Nominal (L/S)
4300 (2030)
6100 (2880)
7000 (3300)
Condenser Coil (Qty.)
1
1
1
Face Area Total - Ft.² (m²)
15.6 (1.45)
23.8 (2.21)
23.8 (2.21)
Rows/FPI (FPM)
2/21 (827)
2/21 (827)
3/16 (630)
Tube Diameter (mm)/Material
3/8 (9.5)/Copper
3/8 (9.5)/Copper
3/8 (9.5)/Copper
Number of Compressors
2
2
3
Volts-Phase
380-415-3
380-415-3
380-415-3
Compressor RLA/LRA
6.7/47.5
9.5/73.0
9.5/73.0
Blower FLA - Indoor/Outdoor
3.4/1.7
4.2/1.7
7.3/1.7
Minimum Circuit Ampacity³
23.6
31.3
49.5
Maximum Fuse Size
30
50
60
Ship Weight - lbs. (kg)
990 (449.5)
1215 (551.6)
1460 (662.8)
¹ Sensible capacity is gross, with no deduction for indoor motor heat
² BTU/Watt @ 80/67°F (26.7/19.4°C) inside - 95°F (35°C) outside air
³ Wire size should be in accordance with Local Electrical Codes. Extensive wire runs will require larger wire sizes.
N
OMENCLATURE
PCB 090 - 5
E
LECTRICAL
D
ESIGNATOR
5 - 380/415 VAC, 3ph, 50Hz
N
OMINAL
C
OOLING
C
APACITY
090 - 90,000 BTU/h
120 - 120,000 BTU/h
180 - 180,000 BTU/h
U
NIT
T
YPE
PCB - Package Cool
