HandyTone-386 User Manual Grandstream Networks, Inc.
6
HandyTone-386 has two FXS ports. The RJ-11 jack next to the LAN is called FXS port 2 and the RJ-
11 jack on the corner is called FXS port 1. The RJ-11 jack on the side on of the HandyTone-386 is a
LINE port or PSTN pass-through port. Each FXS port can have a separate SIP account. This is a key
feature of HandyTone-386. Both ports can make calls concurrently.
Following are the steps to install a HandyTone-386:
1. Connect a standard touch-tone analog telephone (or fax machine) to FXS port 1.
2. Connect another standard touch-tone analog telephone (or fax machine) to FXS port 2.
3. Insert a standard telephone cable into the LINE port of HandyTone-386 and connect the other
end of the telephone cable to a wall jack.
4. Insert the Ethernet cable into the LAN port of HandyTone-386 and connect the other end of the
Ethernet cable to an uplink port (a router or a modem, etc.)
5. Insert the power adapter into the HandyTone-386 and connect it to a wall outlet.
Please follow the instructions in section 6.2.1 to configure the HandyTone-386.
