13
37
10
69
10
2
Weight
Storage
Tube
15
ATTACHING THE CURL BAR
Attach the Curl Bar Frame (15) to the Leg Lever (10)
with the Short Pin (37).
USING YOUR WEIGHTS
To use the Leg Lever (10), slide the desired weights
(not included) onto the Leg Lever. Secure the weights
with the Weight Clip (69).
See the inset drawing. Unused weights can be stored
on the tube on the Storage Base (2).
WARNING:
Do not put more than
150 lbs (68 kg) on the Leg Lever (10). Do not
put more than 310 lbs (141 kg) on the Weight
Rests (7) or the Safety Spotters (6). Always
secure weights with the Weight Clip (69).
8
47
16
9
ATTACHING THE CURL PAD
To use the Curl Pad (16), insert the Curl Post (8) into
the Front Leg (9) and secure the Curl Post with the
Curl Knob (47).
Firmly tighten the Curl Knob.
