Optional AQL-CHEM2 CO
2
Dispensing Kit
The AQL-CHEM2 is a CO
2
dispensing device that connects directly to the Pro Logic. When used with an AQL-
CHEM, the Pro Logic will sense the pool’s pH level and automatically dispense the correct amount of CO
2
to control
the pool’s pH to the desired level. Wiring and plumbing requirements for the AQL-CHEM2 should be considered
before installing the Pro Logic. Refer to the AQL-CHEM2 manual for specific installation information.
Optional Remote Controls
Goldline offers a variety of wired and wireless remote control options for the Pro Logic. Each model gives you the
ability to control your pool’s functions from a remote location, away from the Control Center.
Wired Remote Controls
Up to 3 wired remote controls can be installed. See page 17 for wiring information.
AQL-WW-P-4
The AQL-WW-P-4 display/keypad must be mounted indoors or in a weather protected area (rain should never touch
the unit). The display/keypad is designed to mount onto a standard electrical utility box (same box as a single light
switch, ideal for new construction) or can be mounted directly onto any wall surface. When selecting a location, note
that the wire to the Pro Logic main unit must be less than 500’ long. Refer to the remote’s installation instructions as well
as the steps below:
1. Remove display/keypad baseplate from the cover by lifting up on the cover at the lower end of the keypad. See
diagram below.
2. Screw the baseplate in the desired position (screws supplied by installer).
3. See “Electrical Wiring” (page 17) for instructions on running the cable from the Pro Logic main unit to the
remote display/keypad.
AQL-SS-6B-x (x=W or B for White or Black)
The AQL-SS-6B is a double insulated, waterproof device which is intended for installation at the water's edge. The
remote control comes with an attached 150’ cable and is typically installed at the tile-line of the spa wall, or in the deck,
within arm's reach of a pool/spa occupant. Refer to the AQL-SS-6B installation manual for specific mounting and
wiring information.
6
Lights Config.
+ to view/change
Lights Function
Manual On/Off
Lights Relay
Standard
Push to access Lights options
Rotates between Manual On/Off (default), Countdown Timer,
Low Speed- Filter, Timeclock, Solar, and Super Chlorinate
Toggle between Standard (default) and Dimmer
Move to previous/next configuration menu
Move to next menu item
Move to next menu item or previous/next configuration menu
Lights Interlock
Disable
Lights Freeze
Disable
Toggle between Enabled and Disabled (default) Lights Interlock
Toggle between Enabled and Disabled (default) Lights Freeze
Move to next menu item
Move to previous/next configuration menu
for all functions except dimmer relay, solar
super chlorinate, and low speed
for all functions except dimmer relay,
super chlorinate, and low speed
for manual on/off, countdown
timer and timeclock functions
for all functions except solar, dimmer relay, super chlorinate
pH dispense and low speed
Lights Ext Input
Disabled
Toggle between Enabled and Disabled (default)
Move to previous/next configuration menu
Lights Function
Although designated as the “Lights” output, the function of the lights relay is similar to the aux1 and aux2
relays. If pool lights are wired to the lights relay, some options including Solar function, Low Speed of a 2-
Speed Filter Pump, Lights Interlock and Lights Freeze Protection will not be necessary and should be
disabled. If no pool lights are used, the lights relay can be used to control other pool devices that may
require these options. The function of each option is shown below.
Manual On/Off (default)—the lights relay will alternate between turning on and off when the LIGHTS
button is pressed. There is no automatic control logic.
Countdown Timer—the lights relay will turn on when the LIGHTS button is pressed. The lights relay will
turn off automatically after a programmed time (see Timers Menu in Operation Manual). The LIGHTS
button can also be used to turn the output off.
Low Speed of a 2-speed Filter Pump – the Pro Logic will turn on the lights relay whenever the low speed
operation of the filter pump is required. It is very important that the “2-speed” filter pump option be
selected under the “Filter Config.” Menu for proper operation.
Timeclock – the lights relay will turn-on and turn-off at the times set for the lights timeclock in the Timers
Menu (see Timers Menu in Operation Manual). The LIGHTS button can also be used to turn the output
on and off.
Solar – the lights relay can operate a solar booster pump which will turn on when the filter pump is running
and solar heat is available and the water is less than the desired temperature setting. It is important to note
that “Solar Control” must be enabled in the “Solar Config.” menu for proper operation to occur.
Super Chlorinate – if “Chlorinator” is enabled, this option allows the user to start a Super Chlorinate cycle
when the Lights button is pressed, rather than using the Settings Menu. Note that only one button can be
assigned to this function.
Lights Relay
This feature allows the user to select either “Standard” (default) or “Dimmer” type relay for the Lights
output. The optional AQL-DIM dimmer kit must be installed if “Dimmer” is desired. When “Dimmer” is
selected, and the Lights output is manually turned on, the “+” and “-” buttons adjust the level from 20%
to 100% (default). The level is saved for the next time the lights are turned from off to on.
Lights Interlock
If enabled, this feature will override the function (Manual On/Off, Countdown Timer, Timeclock) selected
above and turn the lights relay off when: filter pump is off, first 3 minutes of filter pump operation (allows
