46
Appendix E
Specifications
1. System
Host Interface PCI 2.3
Operating Voltage 3.3VDC ± 5%
2. RF Performance
802.11b
Frequency Band 2412 ~ 2484 MHz (subject to local regulation)
Modulation Technology DSSS (Direct Sequence Spread Spectrum)
Modulation Techniques CCK, DQPSK, DBPSK
Date Rates 11, 5.5, 2, 1Mbps, auto fallback
Typical Power Consumption
Doze: 25mA
Receive: 250mA
Transmit: 560mA
Peak Output Power 21dBm @ Nominal Temp Range
Minimum Receive Sensitivity -85dBm @ 11 Mbps, Nominal Temp Range
Antenna External antenna with the gain of 2dBi, L type
802.11g(backward compatible to 802.11b)
Frequency Bands 2412-2484 MHz (subject to local regulations)
Modulation Technology OFDM and DSSS
Modulation Techniques 64QAM, 16QAM, QPSK, BPSK, CCK, DQPSK,
DBPSK
Date Rates Base mode: 54, 48, 36, 24, 18,12, 9, 11, 6, 5.5, 2,
and 1 Mbps, auto fallback
Turbo mode: 108, 96, 72, 48, 36, 24, 18 and 12
Mbps auto fallback
Typical Power Consumption
Doze: 25mA
Receive: 250 mA
Transmit: 530 mA
Peak Output Power 20dBm @ Nominal Temp Range
Receive sensitivity Minimum -72dBm; typical -74dBm @54Mbps,
Nominal Temp Range
Antenna External antenna with the gain of 2dBi, L type
