Super G Wireless PCI Adapter
21
searches for a channel.
Frequency - The radio frequency that your client adapter is currently using
for communications. This field displays "Scanning" while the client adapter
searches for a frequency.
Channel Set - The regulatory domain for which your client adapter is
currently configured. This value is not user selectable. ( America, EMEA,
Japan, or Rest of World)
Click OK to close the Advanced Status window.
Site Survey Tab
The Site Survey screen displays a list of infrastructure and Ad-hoc networks
available for connection in the “Network Name” column. To connect to a
network, simply click on the network name, and press the Activate button. Note
that secure networks (represented by the key icon) will require a Passphrase.
Figure 16. Site Survey Tab
Network Name – The SSID or unique name of the wireless network.
Key Icon - Indicates a secure or open network
Signal Strength – The strength of signal, reported in dB.
