Magnum 10Mb Media Converters
Installation and User Guide (07/98)
GARRETT
3
Power Supply (External):
Power Input: 95 - 125 vac at 60 Hz for U.S. and Canadian models,
200 - 250 vac at 50 Hz for international models which have
IEC power cable connector.
Power Consumption: 6 watts max. for the Media Converter
Connectors:
RJ-45 Port: Modular 8-Pin female, with “cross-over” up-link switch
BNC Port: Standard BNC connector, RG-58 ThinNet
Fiber Port: Fiber optic (standard ST & SC types), 10BASE-FL
Fiber, Full- and half-duplex:
Fiber models capable of full- or half-duplex transparent operation have a tag on
the bottom marked “FULL/HALF DUPLEX”, and do not indicate collisions.
