GFK-2251 Appendix A Product Agency Approvals, Standards, and General Specifications A-3
A
General Specifications
GENERAL SPECIFICATIONS Standard(s) Conditions
ISOLATION
Dielectric Withstand UL 508, UL 840,
IEC 664 1.5KV DC (input power to secondary outputs)
ENVIRONMENTAL
Vibration IEC 68-2-6 10 - 57 Hz, 0.012" displacement peak-peak
57 - 500 Hz, 1.0g acceleration
Shock
IEC 68-2-27 15g, 11ms, sinusoidal
Operating Temperature 0°C to 50°C
Storage Temperature -20°C to +60°C
Humidity 5% to 95% RH (non-condensing)
Enclosure Protection NEMA 250 NEMA Type 4, 4x and 12 when mounted in panel
EMC EMISSIONS [applies to CE Marked units]
Radiated, Conducted
CISPR 11/EN 55011 “Industrial Scientific & Medical Equipment”
(Group 1, Class A)
CISPR 22/EN 55022 “Information Technology Equipment” (Class A)
47 CFR 15 referred to as FCC part 15, “Radio Devices” (Class A)
Harmonics
EN 61000-3-2 Class D
EMC IMMUNITY [applies to CE Marked units]
Electrostatic Discharge EN 61000-4-2 ±8KV Air, ±4KV Contact
RF Susceptibility EN 61000-4-3 10Vrms /m, 80Mhz to 1000Mhz, 80% AM, 1kHz sine wave
ENV 50140/
ENV 50204 10Vrms /m, 900 ± 5Mhz, 100% PM, 200Hz square wave
Fast Transient Burst EN 61000-4-4 ±2KV: AC Input Port
±1KV: Signal Ports
Surge Withstand EN 61000-4-5 ±2KV (12Ω) CM, ±1kV (2Ω) DM: AC Input Port
±1kV (2Ω) CM: Signal Ports (shielded)
ANSI C37.90A +2.5KV CM & DM: AC Input Port
+2.5KV CM: Signal Ports (shielded)
Conducted RF EN 61000-4-6 10Vrms, 0.15 to 80Mhz, 80%AM: AC Input & Signal Ports
Input Dips & Variation EN 61000-4-11 AC Input Dips: 30 & 100% Nominal (10ms)
AC Input Variation: ±10% Nominal (10s)
Voltage Flicker EN 61000-3-3 D
t
< 3.3%, D
c
< 3.3%, D
max
< 4.0%, P
st
< 1.0: AC Input Port
