5-4
Panel C Industrial Computer Hardware User's Manual
– May 2003
GFK-2251
5
Table 5-1. Membrane Keypad Scan Codes [Reviewers: Verify AT Character and scan codes here]
Without SHIFT Key
With SHIFT Key
With CAPS LOCK Key
Keypad
AT
Character
Scan
Code
(Hex)
AT
Character
Scan
Code
AT
Character
Scan
Code
(Hex)
7
7
0837
\
2B5C
\
2B5C
8
8
0938
/
352F
/
352F
9
9
0A39
:
273A
:
273A
4
4
0534
;
273B
;
273B
5
5
0635
,
332C
,
332C
6
6
0736
"
2822
"
2822
1
1
0231
%
0625
%
0625
2
2
0332
[
1A5B
[
1A5B
3
3
0433
]
1B5D
]
1B5D
0
0
0B30
_
0C5F
_
0C5F
-
-
4A2D
+
4E2B
+
4E2B
. (PERIOD)
. (PERIOD)
342E
?
353F
?
353F
INSERT
Insert
5200
*
372A
*
372A
ENTER
ENTER
1C0D
ENTER
1C0D
ENTER
1C0D
ESCAPE
Escape
011B
Escape
011B
Escape
011B
TAB
Tab
0F09
Shift Tab
0F00
Shift Tab
0F00
None
None
None
None
None
None
SPACE
Space
3920
Space
3920
Space
3920
ALT
Left
alternate
None
None
None
None
None
CTRL
CTRL
None
None
None
None
None
DELETE
Delete
5300
Delete
5300
Delete
5300
PAGE
↑
Pageup
4900
Pageup
4900
Pageup
4900
BKSP
BKSP
0E08
BKSP
0E08
BKSP
0E08
HOME
Home
4700
Home
4700
Home
4700
PAGE
↓
Pagedown
5100
Pagedown
5100
Pagedown
5100
END
End
4F00
End
4F00
End
4F00
←
Left arrow
4B00
Left arrow
4B00
Left arrow
4B00
→
Right arrow
4D00
Right arrow
4D00
Right arrow
4D00
↑
Up arrow
4800
Up arrow
4800
Up arrow
4800
↓
Down arrow
5000
Down
arrow
5000
Down
arrow
5000
LOCK
CAPS
LOCK CAPS
None
None
None
None
None
SHIFT (1)
SHIFT (1)
None
None
None
None
None
F1
F1
3B00
a
1E61
A
1EF1
F2
F2
3C00
b
3062
B
3042
F3
F3
3D00
c
2E63
C
2E43
F4
F4
3E00
d
2064
D
2044
F5
F5
3F00
e
1265
E
1245
F6
F6
4000
f
2166
F
2146
F7
F7
4100
g
2267
G
2247
F8
F8
4200
h
2368
H
2348
F9
F9
4300
i
1769
I
1749
F10
F10
4400
J
246A
J
244A
F11
F11
8500
k
256B
K
254B
F12
F12
8600
l
266C
L
264C
