Grizzly G0492 - Manual (Page 55)

G0492 12" X 36" Combo Lathe/Mill
-53-
3000 Series Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
3001 P04923001 SPANNER NUT M16-1.5 3056 PK128M KEY 5 X 5 X 60
3002 P04923002 TANG WASHER 3057 P04923057 SPACER SLEEVE
3003 PW08M FLAT WASHER 16MM 3058 P04923011 BALL BEARING 203
3004 PK08M KEY 5 X 5 X 16 3059 P04923059 SLEEVE
3005 P04923005 SPINDLE PULLEY 3060 P04923060 END CAP
3006 P04923006 TAPER ROLLER BEARING 60206 3062 PSS03M SET SCREW M6-1 X 8
3007 PSB33M CAP SCREW M5-.8 X 12 3064 P04923064 FIXED FLANGE
3008 P04923008 HUB 3065 P04923065 SPANNER WASHER 45MM
3009 P04923009 FELT SEAL 3066 P04923066 SHIFT FORK SHAFT
3010 PR06M EXT RETAINING RING 16MM 3067 PR03M EXT RETAINING RING 12MM
3011 P04923011 BALL BEARING 203 3068 P04923068 KNOB M8-1.25 FEMALE
3012 P04923012 HEADSTOCK CASTING 3069 P04923069 LEVER
3013 P04923013 GASKET 3070 P04923070 LEVER HUB
3014 P04923014 HEADSTOCK COVER 3071 P04923071 OIL DRAIN
3015 PSB13M CAP SCREW M8-1.25 X 30 3072 P04923072 RIGHT SHIFTING FORK
3016 P04923016 O-RING 30 X 20 X 2MM 3073 P04923073 RIGHT SHIFTING FORK SHAFT
3017 P04923017 FILL PLUG 3074 P04923074 O-RING
3018 P04923018 SIGHT GLASS 3075 P04923075 FIXED FLANGE
3019 P04923019 SPINDLE SHAFT 3077 P04923077 STEEL BALL 6.5MM
3020 P04923020 GEAR (42-TOOTH) 3078 P04923078 COMPRESSION SPRING
3021 P04923021 GEAR (20-TOOTH) 3079 P04923079 TAPER PIN
3022 P04923022 SLEEVE SPACER 3080 P04923080 KNOB M8-1.25 FEMALE
3023 P04923023 GEAR (30-TOOTH) 3081 P04923081 LEVER
3024 PK13M KEY 5 X 5 X 70 3082 P04923082 LEVER HUB
3025 PR07M EXT RETAINING RING 18MM 3083 P04923083 TAPER PIN
3026 P04923011 BALL BEARING 203 3084 P04923084 COMPRESSION SPRING
3027 P04923027 BEARING SLEEVE 3085 P04923077 STEEL BALL 6.5MM
3028 P04923028 END CAP 3087 P04923087 FLANGE
3030 PSS03M SET SCREW M6-1 X 8 3088 P04923088 OIL SEAL 16 X 2.4MM
3031 PR78M EXT RETAINING RING 55MM 3089 P04923089 LEFT SHIFTING FORK SHAFT
3032 P04923032 THIN FLAT KEY 3090 P04923090 LEFT SHIFTING FORK
3033 P04923033 GEAR (56-TOOTH) 3091 P04923011 BALL BEARING 203
3034 P04923034 TAPER ROLLER BEARING D2007112 3092 P04923092 SPANNER WASHER
3035 P04923035 SPANNER WASHER 120MM 3093 P04923093 FELT RING
3036 P04923036 FELT RING 3094 P04923094 FLANGE
3037 P04923037 MAINSHAFT OIL SEAL 3096 P04923096 KEYED DRIVE GEAR
3038 PB42M HEX BOLT M5-.8 X 20 (24-FINE TOOTH)
3039 P04923039 LATHE SPINDLE 3096-1 P04923096-1 KEYED DRIVE GEAR SET
3040 PR09M EXT RETAINING RING 20MM (28 & 35-COARSE TOOTH)
3041 P04923041 CLUSTER GEAR 3097 PK05M KEY 4 X 4 X 10
3042 PK128M KEY 5 X 5 X 60 3098 PLW06M LOCK WASHER 10MM
3043 PR09M EXT RETAINING RING 20MM 3099 PN02M HEX NUT M10-1.5
3044 P04923044 COMBO GEAR (22/57-TOOTH) 3100 P04923011 BALL BEARING 203
3045 PK02M KEY 5 X 5 X 40 3101 P04923101 SPANNER WASHER 60MM
3046 P04923046 INTERMEDIATE SHAFT 3102 P04923102 END CAP
3047 P04923011 BALL BEARING 203 3104 P04923104 TAPER ROLLER BEARING 2007110
3048 P04923048 SLEEVE 3105 P04923105 SPECIAL WASHER
3049 P04923049 END CAP 3106 P04923106 SPANNER WASHER 105MM
3051 PSS03M SET SCREW M6-1 X 8 3107 P04923107 FELT RING
3052 P04923052 OUTPUT SHAFT 3108 P04923108 END CAP
3053 P04923053 HUGE GEAR (68-TOOTH) 3109 P04923109 CAP SCREW
3054 P04923054 GEAR (33-TOOTH) 3110 P04923110 TANG WASHER
3055 P04923055 GEAR (56-TOOTH) 3111 P04923111 SPANNER NUT
