G0492 12" X 36" Combo Lathe/Mill
-51-
2700 Series Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2701 P04922701 COVER PLATE 2727 PSB24M CAP SCREW M5-.8 X 16
2702 PS05M PHLP HD SCR M5-.8 X 8 2728 P8102 BEARING 8102
2703 P04922703 BALL OILER 8MM 2729 P04922729 SPANNER NUT
2704 P04922704 SPECIAL SET SCREW M5-.8 X 6 2730 P04922730 FLANGE HUB
2705 P04922705 SHAFT 2731 P04922731 KNOB M8-1.25 FEMALE
2706 PK08M KEY 5 X 5 X 16 2732 P04922732 LEVER
2707 P04922707 GEAR (20-TOOTH) 2733 P04922733 LEVER HUB
2708 P04922708 SPACER 2734 P04922734 TAPER PIN
2709 P04922709 SLEEVE 2735 P04922735 SHIFTING YOKE
2710 P04922710 PLUG 2736 P04922736 SHIFTING FORK
2711 P04922711 SHAFT 2737 P04922737 LOCATING PLATE
2712 PK127M KEY 5 X 5 X 8 2738 PFH07M FLAT HD SCR M5-.8 X 10
2713 P04922713 GEAR (20-TOOTH) 2739 P04923077 STEEL BALL 6.5MM
2714 P04922714 SPACER 2740 P04922740 COMPRESSION SPRING
2715 P04922715 GEAR (20-TOOTH) 2741 PS12M PHLP HD SCR M3-.5 X 6
2716 P04922716 SPACER 2742 P04922742 FRONT PANEL
2717 P04922717 SLEEVE 2743 P04922743 CAP SCREW M8-1.25 X 100
2718 P04922718 PLUG 2744 P04922744 HOUSING
2719 P04922719 COVER PLATE 2745 P04922745 BUSHING
2720 PS07M PHLP HD SCR M4-.7 X 8 2746 P04922746 PLUG
2721 PR06M EXT RETAINING RING 16MM 2747 P04922747 FLANGE HUB
2722 P04922722 GEAR (20-TOOTH) 2748 PSB33M CAP SCREW M5-.8 X 12
2723 PK126M KEY 5 X 5 X 32 2749 P04922749 BUSHING
2724 P04922724 SHAFT 2750 P04922750 PLUG
2725 P8102 BEARING 8102 2751 P04922751 BUSHING
2726 P04922726 FLANGE HUB
