GA-K8U-939 Motherboard - 68 -
English
2. Create RAID 1 Mirroring for Reliability
Press Enter on Create RAID 1 Mirroring for Reliability item. An "M" flash cursor appears at the Drive
Select Menu for the user to choose the first(source) drive for RAID 1. Use Space key to select the desired
drive for RAID 1. Then the flash cursor changes to an "m" flash cursor for the user to choose the second
(target) drive for RAID 1. (as Figure below)
Press Space key to select the second drive. The prompt "Create RAID 1 (Y/N)?" appears after two drives
are properly assigned. Press Y, and then some necessary information will be written to the drives, which will
destroy the original data in the drives.
RAID BIOS Setup Utility (c) 2004 ALi Corporation www.ali.com.tw
SPACE : Select
, : Moving Cursor
Enter : Select & Finish
ESC : Exit
Drive Model Mode Capacity RAID Array/Type
Channel 1 Master : ST3120026AS SATA 1 120034 MB
Channel 2 Master : ST3120026AS SATA 1 120034 MB
Capacity RAID Type Stripe Size RAID Name
RAID Array A :
RAID Array B :
RAID Array C :
Create RAID 0 Striping for Performance
Create RAID 1 Mirroring for Reliability
Create JBOD for integrated Capacity
Stripe Size
64K
Delete RAID Settings & Partition
Delete All RAID Settings & Partition
Rebuild RAID Array
M
m
Select Stripe Drives
It is recommended to use new drives to create RAID 1. If existing drive is to be used, backup all
necessary data before creating RAID 1.
Next, the Array Name input line appears for the user to key in a name for the newly created array. The
effective characters for an array name is 0-9, A-Z, a-z, space and underscore.
Lastly a prompt message "Duplicate Data from M to m (Y/N)?" asks whether to do drive copy. The source
and target drives are indicated by "M" and "m" in Drive Select Menu respectively. Pressing Y will duplicate
the data in source drive to the target drive. Make sure the source drive is the correct one. If you press N, then
the data is inconsistent in two drives.
RAID BIOS Setup Utility (c) 2004 ALi Corporation www.ali.com.tw
SPACE : Select
, : Moving Cursor
Enter : Select & Finish
ESC : Exit
Drive Model Mode Capacity RAID Array/Type
Channel 1 Master : ST3120026AS SATA 1 120034 MB
Channel 2 Master : ST3120026AS SATA 1 120034 MB
Capacity RAID Type Stripe Size RAID Name
RAID Array A :
RAID Array B :
RAID Array C :
Create RAID 0 Striping for Performance
Create RAID 1 Mirroring for Reliability
Create JBOD for integrated Capacity
Stripe Size
64K
Delete RAID Settings & Partition
Delete All RAID Settings & Partition
Rebuild RAID Array
M
m
Duplicate Data from M to m (Y/N) ?
