GA-K8U-939 Motherboard - 42 -
English
2-7 Frequency/Voltage Control
CMOS Setup Utility-Copyright (C) 1984-2005 Award Software
Frequency/Voltage Control
K8 CPU Clock Ratio [Default]
Auto Detect PCI Clk [Enabled]
CPU Clock [200MHz]
CPU OverVoltage Control [Auto]
DIMM OverVoltage Control [Auto]
VCC18 OverVoltage Control [Auto]
VCC12 OverVoltage Control [Auto]
AGP OverVoltage Control [Auto]
KLJI: Move
Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level`
K8 CPU Clock Ratio
Default Set K8 CPU Clock Ratio to CPU factory default. (Default value)
x4 800Mhz ~ x9 1800Mhz. Set K8 CPU Clock Ratio from x4 800Mhz to x9 1800Mhz.
Auto Detect PCI Clk
Enabled Detect PCI clock automatically. (Default value)
Disabled Disable this function.
CPU Clock
200 ~ 232MHz Set CPU clock from 200Mhz to 232Mhz.
CPU OverVoltage Control
Auto Supply voltage as CPU required. (Default value)
+5%, +7.5%, +10% Increase voltage range as user selected.
DIMM OverVoltage Control
Auto Supply voltage as DDR module required. (Default value)
+0.1V, +0.2V Increase voltage range as user selected.
VCC18 OverVoltage Control
Auto Supply voltage as VCC18 required. (Default value)
+5%, +7.5%, +10% Increase voltage range as user selected.
VCC12 OverVoltage Control
Auto Supply voltage as VCC12 required. (Default value)
+5%, +7.5%, +10% Increase voltage range as user selected.
AGP OverVoltage Control
Auto Supply voltage as AGP required. (Default value)
+5%, +7.5%, +10% Increase voltage range as user selected.
Incorrect using these features may cause your system broken. For power end-user use only.
