Next, the Array Name input line appears for the user to key in a name for the newly created array. The
effective characters for an array name is 0-9, A-Z, a-z, space and underscore.
RAID BIOS Setup Utility (c) 2004 ALi Corporation www.ali.com.tw
SPACE : Select
, : Moving Cursor
Enter : Select & Finish
ESC : Exit
Drive Model Mode Capacity RAID Array/Type
Channel 1 Master : ST3120026AS SATA 1 120034 MB
Channel 2 Master : ST3120026AS SATA 1 120034 MB
Capacity RAID Type Stripe Size RAID Name
RAID Array A :
RAID Array B :
RAID Array C :
Create RAID 0 Striping for Performance
Create RAID 1 Mirroring for Reliability
Create JBOD for integrated Capacity
Stripe Size
64K
Delete RAID Settings & Partition
Delete All RAID Settings & Partition
Rebuild RAID Array
S
s
Input RAID Name (8 characters) : ALi_RAID
After the RAID array has been created successfully, its information shows up at RAID Array List.
RAID BIOS Setup Utility (c) 2004 ALi Corporation www.ali.com.tw
SPACE : Select
, : Moving Cursor
Enter : Select & Finish
ESC : Exit
Drive Model Mode Capacity RAID Array/Type
Channel 1 Master : ST3120026AS SATA 1 120034 MB
Channel 2 Master : ST3120026AS SATA 1 120034 MB
Capacity RAID Type Stripe Size RAID Name
RAID Array A : 240 GB 0 64K ALi_RAID
RAID Array B :
RAID Array C :
Create RAID 0 Striping for Performance
Create RAID 1 Mirroring for Reliability
Create JBOD for integrated Capacity
Stripe Size
64K
Delete RAID Settings & Partition
Delete All RAID Settings & Partition
Rebuild RAID Array
Before create the RAID Array, you can select the Stripe Size first. The Stripe Size is effective for
RAID 0. The user can choose a stripe size from 64KByte, 32KByte, 16KByte(default), 8KByte and
4KByte. If the user uses RAID 0 for most A/V editing application or files, 64KByte is recommended.
