222 PMCS Interface Toolkit
• Normal Pickup
• Normal Dropout
• Emer Pickup
• Emer Dropout
The user can enter values against each parameter.
Frequency (Hz)
• Normal Pickup
• Emer Pickup
The user can enter values against each parameter.
Time (Seconds)
• P Time
• W Time
• W3 Time
• DW Time
• T Time
• T3 Time
• DT Time
• U Time
The Setup tab also provides push buttons for performing the following commands:
Download – Executes a script to check for values that have changed and downloads those values to the device
Refresh – Executes a script to upload all of the meter values for the settings on the screen.
Note: Be sure to click the Refresh button prior to changing or downloading any settings to the MX 200, as the latest
settings may not be displayed.
