95
Page Value Text Displayed Description
17 TIME OVERCURRENT
PHASE ABC
or
TIME OVERCURRENT GROUND
or
INST OVERCURRENT PHASE ABC
or
UNDERVOLTAGE FAULT
or
OVERVOLTAGE FAULT
or
EXTERNAL TRIP #x
or
ANALOG INPUT
or
POWER FACTOR FAULT
or
FREQUENCY FAULT Only phases in alarm are displayed
x is in range 1-4
18 PHASE A PRE-TRIP
CURRENT xxx A Value in amps
19 PHASE B PRE-TRIP
CURRENT xxx A Value in amps
20 PHASE C PRE-TRIP
CURRENT xxx A Value in amps
21 GROUND PRE-TRIP
CURRENT xxx A Value in amps
22 PRE -TRIP VOLTAGE
A-B xxx.xx kV
or
A-N xxx.xx kV
If configured as Delta
or
If configured as Wye
23 PRE -TRIP VOLTAGE
B-C xxx.xx kV
or
B-N xxx.xx kV
If configured as Delta
or
If configured as Wye
24 PRE -TRIP VOLTAGE
C-A xxx.xx kV
or
C-N xxx.xx kV
If configured as Delta
or
If configured as Wye
25 FREQUENCY AT
TRIP xxx.xx Hz
26 DATE OF TRIP
xx/xx/xx mm/dd/yy
27 TIME OF TRIP
xx:xx:xx hh:mm:ss
28 PRE-TRIP DATA
END OF PAGE Page footer
