H7949/H7950/H7951 Nailer -20 -
REF PART # DESCRIPTION REF PART # DESCRIPTION
79 PH7949079 PILOT VALVE 92 PH7949092 CONTACT TRIP BLOCK
80 PH7949080 O-RING 93 PH7949093 ADJUSTING BOLT
81 PH7949081 BALL PIN 94 PH7950094 COVER
82 PH7949082 TRIGGER VALVE HOUSING 95 PH7949095 O-RING
83 PH7949083 O-RING 96 PH7949096 RUBBER GRIP
84 PH7949084 O-RING 97 PH7949097 ADJUSTING NUT
85 PH7949085 TRIGGER PLATE 98 PH7950098 NAILER CASE
86 PH7949086 TRIGGER 100 PH7949100 INCLUDED PNEUMATIC OIL
87 PRP98M ROLL PIN 3 X 16 101 PAW04M HEX WRENCH 4MM
88 PH7949088 SLIDE SHAFT 102 PAW05M HEX WRENCH 5MM
89 PH7949089 SPRING 103 PH7950103 PISTON REPAIR KIT
90 PH7949090 TRIP GUIDE 104 PH7950104 MACHINE LABEL
91 PH7949091 SPRING 105 PH7950105 SPRING
H7950 PARTS LIST
PAGE 2 OF 2
