Grizzly H7949 User Manual
Page 21
H7949/H7950/H7951 Nailer
-19
-
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
1
PFH06M
FLAT HD CAP SCR M6-1 X 20
40
PH7949040
STEPPED PIN
2
PH7949002
FRONT BRACKET
41
PH7949041
O-RING
3
PH7950003
EXHAUST COVER
42
PH7949042
FEED PISTON
4
PH7949004
EXHAUST FILTER
43
PH7949043
O-RING
5
PH7950005
EXHAUST FILTER PLATE
44
PH7949044
SPRING
6
PSB06M
CAP SCREW M6-1 X 25
45
PH7949045
SPRING
7
PH7950007
CAP
46
PH7949046
FEED PISTON STOP
8
PH7949008
SPRING
47
PH7949047
SPRING COLLAR
9
PH7949009
WASHER
48
PH7949048
O-RING
10
PH7949010
O-RING
49
PH7950049
STEPPED PIN
11
PH7949011
PISTON HEAD VALVE
50
PH7949050
RATCHET
12
PH7949012
O-RING
51
PH7949051
SPRING
13
PH7949013
SEAL
52
PH7950052
DOOR
14
PH7949014
PLAIN WASHER
53
PH7949053
NAIL SUPPORT
15
PH7949015
PISTON STOPPER
54
PH7949054
SPRING
16
PH7950016
O-RING
55
PH7949055
SET SHAFT
17
PH7950017
PISTON
56
PH7949056
SLIDE ROD
18
PH7950018
DRIVER
57
PH7950057
MAGAZINE
19
PH7950019
CYLINDER
58
PSBS09M
BUTTON HD CAP SCR M5-.8 X 12
20
PH7950020
O-RING
59
PSB15M
CAP SCREW M5-.8 X 20
21
PH7950021
CYLINDER RING
60
PLN02M
LOCK NUT M5-.8
22
PH7950022
COLLAR
61
PH7949061
MAGAZINE COVER
23
PH7950023
O-RING
62
PRP42M
ROLL PIN 3 X 20
24
PH7950024
GASKET
63
PH7949063
RUBBER INSERT
25
PH7950025
BODY
64
PH7950064
SAFETY LEVER
26
PH7949026
PAD
65
PH7949065
DUST COVER
27
PH7949027
O-RING
66
PW03M
FLAT WASHER 6MM
28
PH7950028
BOTTOM BUMPER
67
PSBS06M
BUTTON HD CAP SCR M5-.8 X 12
29
PH7949029
O-RING
68
PH7950068
NOSE COVER
30
PH7950030
NOSE
69
PH7950069
PALLET TIP
31
PSB14M
CAP SCREW M8-1.25 X 20
70
PH7950070
SIDING TIP
32
PH7949032
STEPPED PIN
71
PH7950071
DECKING TIP
33
PH7949033
RETAIN RUBBER
72
PRP97M
ROLL PIN 3 X 30
34
PH7949034
RETAIN RUBBER
73
PH7949073
TRIGGER VALVE CAP
35
PH7949035
CHECK PAWL
74
PH7949074
O-RING
36
PH7949036
SPRING
75
PH7949075
PLUNGER
37
PH7949037
STEPPED PIN
76
PH7949076
SPRING
38
PH7950038
PROTECTOR
77
PH7949077
O-RING
39
PH7949039
FEED PAWL
78
PH7949078
O-RING
H7950 PARTS LIST
PAGE 1 OF 2
