-20- G5963 Surface Grinder
Customer Service #: (570) 326-3806 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Design Type ......................................................................................................Floor Model
Overall Dimensions:
Height ....................................................................................................................57 1 ⁄
2
''
Length ......................................................................................................................33''
Width ....................................................................................................................36
1 ⁄
2
''
Column Diameter........................................................................................................5''
Table Size ........................................................................................................6" x 12''
T-Slot and Size ................................................................................
1 ⁄
2
'' Stud; 7 ⁄
8
" Head
Spindle Diameter ....................................................................................................1 1 ⁄
4
''
Shipping Weight ................................................................................................660 lbs.
Net Weight ........................................................................................................533 lbs.
Footprint ........................................................................................................20" x 20"
Capacity:
Max. Wheel Size ....................................................................................7" x 1 1 ⁄
4
'' x 1 ⁄
2
''
Max. Distance, Wheel to Table ..............................................................................8 7 ⁄
8
''
Longitudinal Travel ................................................................................................13 1 ⁄
4
''
Cross Travel ............................................................................................................7 1 ⁄
8
''
Spindle Speed (RPM) ............................................................................................3450
Construction ....................................................................................................Cast Iron
Motor:
Type ............................................................................TEFC Capacitor Start Induction
Horsepower ..........................................................................................................
3 ⁄
4
HP
Phase ⁄ Voltage ..................................................................Single Phase; 110V ⁄ 220V
Amps ................................................................................................................7.4 ⁄ 3.7
Prewired ................................................................................................................110V
Cycle and RPM ....................................................................................60 Hertz ⁄ 3450
Bearings ..................................................................Shielded, Permanently Lubricated
Features:
....................................................................................................................Lubrication
..................................................................................................................Column Dial
............................................................................................................Cross Feed Dial
..............................................................................Heavy Gauge Sheet metal Cabinet
....................................................................................................One Shot Lubrication
.........................................................0.001" Graduations ⁄ Large Face Dial .50" ⁄ rev.
.....................................................0.001" Graduations ⁄ Medium face Dial .001" ⁄ rev.
..................................................................................................Power Indicator Lights
Accessories:
..................................................................................................Tool Box w⁄ Wrenches
..........................................................................................Grinding Stone Balance Kit
........................................................................................Dressing Diamond w ⁄ Mount
................................................................................................................Leveling Pads
..............................................................................................................Grinding Wheel
Specifications, while deemed accurate, are not guaranteed.
GRIZZLY MODEL G5963 MANUAL SURFACE GRINDER
REVISED 1/2000
