Overview – Grizzly G5963 User Manual
Page 14
-12-
G5963 Surface Grinder
DO NOT make adjustments while the surface
grinder is running. Ensure that the switch is off,
power is disconnected and moving parts have
stopped before making adjustments. Failure to
comply could result in serious injury or electri-
cal shock hazard.
SECTION 5: OPERATIONS
Overview
Once assembly has been completed, the G5963
Surface Grinder is ready for use in the shop.
Many adjustments have already been made at
the factory, yet we recommend you familiarize
yourself with all of the following procedures to
gain a better understanding of the Surface
Grinder’s construction and operation.
Control locations are shown in Figure 5.
ON/OFF Switch
Cross Feed Handwheel
Table Dogs
Table Travel
Handwheel
One-Shot
Lubricator
Guard
Grinding Wheel
Vertical Adjustment
Handwheel
Figure 5. Overview of surface grinder controls.
