Guardian Technologies 4270 User Manual
Page 84
Page 82
Section 9
Exploded Views / Part Numbers
4
14
13
12
1
2
16
& 04614 ONLY)
(MODEL 04270
8
19
19
26
29
28
3
3
20
17
10
18
7
6
27
5
9
1.0 Liter Diesel Injector Pump – Drawing No. 075686-C
ITEM QTY.
DESCRIPTION
1
1
INJECTOR PUMP ASSEMBLY
2
AR
SHIM-0.2MM
AR
SHIM-0.3MM
AR
SHIM-0.5MM
AR
SHIM-1.0MM
3
3
NUT
4
2
BOLT
5
3
GASKET
6
3
INSERT
7
3
CAP
8
3
INJECTOR
9
1
TUBING
10
1
TUBING
11
1
TUBING
12
1
TUBING
ITEM QTY.
DESCRIPTION
13
1
CLAMP
14
1
BOLT
16
3
GLOW PLUG
17
1
CONNECTOR
18
1
GASKET
19
1
COVER (ALL MODELS EXCEPT
04270 & 04614)
1
TUBE, ENGINE OIL FILL (MODEL
04270 & 04614)
20
2
BOLT
26
1
SOLENOID
27
1
WASHER
28
1
WASHER
29
1
SCREW
AR - AS REQUIRED
