19 221834B
Diagram 7.8
Diagram 7.9
✽ STD FLUE TERMINAL = 63
✽ LONG FLUE TERMINAL = 61
✽
FLUE
TERMINAL
FLUE
DUCT
"Q"
"Q" minus 25mm
FOAM SEAL
6867
6868
7 Flue Installation
Diagram 7.7
FOAM SEAL
10mm
"Q"
6866
Diagram 7.6
FLUE DUCT
SEALANT
AIR DUCT/
TERMINAL
ASSEMBLY
FLUE DUCT
4080
7.6 Wall Liner
If a wall liner is used, fit self adhesive seal as follows :
For wall thicknesses up to 300mm fit the self adhesive seal to
the air duct, see diagram 7.7, make sure the joint is on top.
For wall thicknesses over 300mm see diagram 7.8.
