Model H3253, H3254, H3255 Spray Gun -5 -
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
TOOL DATA SHEET
SIPHON FEED SPRAY GUN MODEL
H3253, H3254, H3255
MODEL H3253 H3254 H3255
CUP SIZE 1 liter 750ml 1 liter
TYPE OF FEED Siphon Siphon Siphon
FLUID TIP 1.8MM 1.3mm 1.8mm
AIR CONSUMPTION 4-7 CFM 3.2 CFM 7-9 CFM
INLET AIR
PRESSURE
3.5-4.2 BAR
50-60 PSI
1.5-3.5 BAR
21-50 PSI
4.5-6 BAR
65-87 PSI
FLUID PRESSURE
Greater Than
10 PSI
Greater Than
10 PSI
Greater Than
10 PSI
CUP MATERIAL Aluminum Aluminum Aluminum
MAX. PATTERN
WIDTH
250mm 150mm 300mm
BODY MATERIAL Painted Metal Painted Metal Painted Metal
MATERIAL USAGE
Medium
Solids, i.e..
Enamels &
Lacquers
Medium to
High Solids,
i.e.. Primers
Medium
Solids, i.e..
Enamels &
Lacquers
WATERBORNE
MATERIAL
COMPATIBLE
NO NO NO
