APPENDIX A
DIP SWITCH BANK B
DIP Switch Monitor
Description
1
A
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
2
B
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
3
C
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
4
D
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
5
E
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
6
F
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
7
G
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
8
H
[OFF] 0 db pre-emphasis, [ON] 6 db pre-emphasis
DIP SWITCH BANK C
DIP Switch
Input
Description
1
1
[OFF] EDID pass-through [ON] EDID set to LOCAL
2
2
[OFF] EDID pass-through [ON] EDID set to LOCAL
3
3
[OFF] EDID pass-through [ON] EDID set to LOCAL
4
4
[OFF] EDID pass-through [ON] EDID set to LOCAL
5
5
[OFF] EDID pass-through [ON] EDID set to LOCAL
6
6
[OFF] EDID pass-through [ON] EDID set to LOCAL
7
7
[OFF] EDID pass-through [ON] EDID set to LOCAL
8
8
[OFF] EDID pass-through [ON] EDID set to LOCAL
DIP SWITCH BANK D
DIP Switch
Input
Description
1
1
[OFF] +5V disabled [ON] +5V enabled
2
2
[OFF] +5V disabled [ON] +5V enabled
3
3
[OFF] +5V disabled [ON] +5V enabled
4
4
[OFF] +5V disabled [ON] +5V enabled
5
5
[OFF] +5V disabled [ON] +5V enabled
6
6
[OFF] +5V disabled [ON] +5V enabled
7
7
[OFF] +5V disabled [ON] +5V enabled
8
8
[OFF] +5V disabled [ON] +5V enabled
