-4-
Model g9036 Mfg. 7/08+
The information contained herein is deemed accurate as of 6/15/2008 and represents our most recent product specifications.
Due to our ongoing improvement efforts, this information may not accurately describe items previously purchased.
PAGE 1 OF 3 Model G9036
MACHINE DATA
SHEET
Customer Service #: (570) 546-9663 · To Order Call: (800) 523-4777 · Fax #: (800) 438-5901
MODEL G9036 13" X 40" GEAR-HEAD FLOOR LATHE
Product Dimensions:
Weight............................................................................................................................................................ 1320 lbs.
Length/Width/Height.................................................................................................................71-1/2 x 30 x 53-1/2 in.
Foot Print (Length/Width)................................................................................................................. 69-1/2 x 15-3/4 in.
Shipping Dimensions:
Type........................................................................................................................................................... Wood Crate
Content............................................................................................................................................................ Machine
Weight............................................................................................................................................................ 1555 lbs.
Length/Width/Height............................................................................................................................. 76 x 30 x 60 in.
Electrical:
Switch........................................................................................... Magnetic Switch with Thermal Overload Protection
Switch Voltage...................................................................................................................................................... 220V
Recommended Breaker Size............................................................................................................................ 15 amp
Plug.......................................................................................................................................................................... No
Motors:
Main
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower.................................................................................................................................................2 HP
Voltage........................................................................................................................................................220V
Prewired......................................................................................................................................................220V
Phase........................................................................................................................................................Single
Amps.............................................................................................................................................................10A
Speed.................................................................................................................................................1725 RPM
Cycle..........................................................................................................................................................60 Hz
Number Of Speeds........................................................................................................................................... 1
Power Transfer ...................................................................................................................... Belt Drive to Gear
Bearings.................................................................................................. Shielded and Permanently Lubricated
Main Specifications:
Operation Info
Swing Over Bed......................................................................................................................................... 13 in.
Dist Between Centers.................................................................................................................................40 in.
Swing Over Cross Slide......................................................................................................................... 7-3/4 in.
Swing Over Saddle................................................................................................................................ 7-3/4 in.
Swing Over Gap...................................................................................................................................18-3/4 in.
Max Tool Bit Size...................................................................................................................................... 5/8 in.
Compound Travel...................................................................................................................................2-7/8 in.
Carriage Travel...........................................................................................................................................35 in.
Cross Slide Travel..................................................................................................................................6-1/8 in.
