16
Mounting the First Opener
Step 11
Attach the opener to the securely bolted post bracket assembly and gate bracket using clevis pins, bushings, and hairpin
clips, or optional Pin Locks (see Accessory Catalog). Verify that the opener is level and adjust the post bracket assembly if
necessary.
Level Opener
Gate In Open Position
LEVEL horizontal cross member
Post Bracket Assembly
bolted to fence post
Clevis Pin, Bushing, and Hairpin Clip
Clevis Pin, Bushing, and Hairpin Clip
Gate Bracket bolted
to gate cross member
Fence Post
Installing the Second Opener
Step 12
Install the second opener on the remaining gate leaf by repeating Step 3 through Step 11, starting on page 13.
After you have mounted the second opener, proceed to Installing the Positive Stops on the next page.
