English, Block diagram – GIGABYTE GA-K8NS ULTRA-939 User Manual
Page 11
Introduction
English
- 11 -
Block Diagram
CPUCLK+/- (800MHz)
HyperTransport
Bus
AGP Slot
4X/8X
AGPCLK
(66MHz)
5 PCI
PCICLK
(33MHz)
AMD K8
Socket 939
CPU
SiI3512
2 Serial ATA
DDR400/DDR333/266/200 DIMM
nVIDIA
nForce
TM
3
Ultra
LPC BUS
8 USB
Ports
ATA33/66/100/133
IDE Channels
IT8712
24 MHz
33 MHz
Game Port
Floppy
LPT Port
PS/2 KB/Mouse
2 COM Ports
BIOS
IR_CIR
AC97 Link
MIC
LINE-IN
LINE-OUT
AC97
CODEC
2 Serial ATA
RJ45
Marvell
8001
LAN1
3 IEEE1394b
TSB82AA2
TSB81BA3
Unbuffered DIMMs
RJ45
ICS 1883
LAN2
