Tools and
Materials
Required
Design Information
Stainless Steel G a s Cooktop
4
• Saw
• Carpenter’s square
• Pipe wrench
• Manual gas line
shut-off valve
• 3/4" NPT x 3/4"
I.D. or 1/2" NPT x
1/2" I.D. flare
union adaptor for
connection to
supply line
• 1/2" NPT x 3/4"
I.D. or 1/2" I.D.
flare union adaptor
for connection to
regulator
• Gas-resistant pipe
joint sealant
• Gas pressure
regulator (supplied)
• 90
° street elbow
(supplied), may be
required with a
downdraft vent
combination
installation.
• Wok ring (accessory
supplied on some
models)
• 5 foot AGA-certified
flexible metal
appliance
connector, 3/4" or
1/2" I.D. to match
gas supply line:
– If required by local
codes, use solid
pipe with fittings.
NOTE: Purchase
new flexible line,
DO NOT USE OLD,
PREVIOUSLY USED
FLEXIBLE LINE.
Advance
planning
installation
options Cooktop and ZVB36 Downdraft Vent
Combination Installation. See page 9.
These cooktops may be installed with a 36"
Monogram Downdraft Vent, models ZVB36.
See page 9 for cutout and clearances.
– The countertop must have a deep flat
surface to accommodate the combined
installation of the cooktop and vent.
– The downdraft vent with blower, motor and
ductwork will occupy the base cabinet.
– Consideration must be given to electrical
and gas supply locations. See page 6.
– Read the Downdraft Vent Installation
Instructions packed with the product, or
to review ahead of time, order Pub. No.
49-80185.
Cooktop and ZTD910 Warming Drawer
Combination Installation. See page 10.
These cooktops may be installed over a
Monogram 30" Warming Drawer, models
ZTD910. See page 10 for cutout and clearances.
– Consideration must be given to electrical and
gas supply locations. See page 6.
– Read the Warming Drawer Installation
Instructions packed with the product, or
to review ahead of time, order Pub. No.
49-8937.
Cooktop and ZET837 Single Oven
Combination Installation. See page 11.
These cooktops may be installed over a
Monogram 30" Oven, model ZET1038.
See page 11 for cutout and clearances.
– Consideration must be given to electrical and
gas supply locations. See page 6.
– Read the 30" Oven Installation Instructions
packed with the product, or to review ahead
of time, order Pub. No. 49-80188.
