7 Loosen the captive thumbscrew at the bottom of the
power supply front, then slide the power supply forward
until it stops.
8 Tilt the power supply forward and lift it up and back to
clear the tab on the bottom of the chassis.
9 Holding the new power supply with the back slightly
elevated, place the new power supply over the tab on the
bottom of the chassis, then rotate it so that it rests flat
on the bottom of the chassis.
10 Slide the power supply back so that the tabs on the
bottom back edge of the power supply slide under the
slots on the bottom of the chassis.
Captive thumbscrew
