-10- Model G1019Z 14" Bandsaw
SECTION 4: ASSEMBLY
Beginning Assembly
Most of your G1019Z Bandsaw has been assem-
bled at the factory, but some parts must be
assembled or installed after delivery. We have
organized the assembly process into steps.
Please follow along in the order presented here.
TOOLS REQUIRED: You will need an adjustable
square, 10mm, 12mm and 14mm open end
wrenches and a Phillips
® and regular screwdriver.
Keep clothing rolled up
and out of the way of
machinery and keep
hair pulled back.
Wear safety glasses dur-
ing the entire assembly
process. Failure to com-
ply may result in serious
personal injury.
Some metal parts may
have sharp edges on
them after they are
formed. Please examine
the edges of all metal
parts before handling
them. Failure to do so
could result in injury.
Disconnect power to the
machine when perform-
ing any maintenance or
assembly. Failure to do
this may result in serious
personal injury.
