Magnum 700X Mini-Concentrators Installation and User Guide (05/98)
GARRETT
i
MAGNUM
   
ETHERNET CONNECTIVITY PRODUCTS
"DESIGNED AND MANUFACTURED IN THE USA"
Overview
Garrett Communications offers the Magnum line of Ethernet LAN physical layer
connectivity products with industry-standard functionality. Magnum products are
available worldwide through OEMs, integrators, representatives, retailers and
international distributors.
Dual Speed 8-port & 16-port Stackable, 10/100 auto-sensing per port
Stackable Hubs, SNMP Optional
10Mb series and 100Mb series, both with optional port modules
Switching Hubs, unmanaged 500-Series and managed 5000-Series
Two-Port Switches
100Mb RJ-45port + 10 / 100Mb combo port, or +FDX fiber port
Workgroup Hubs
10Mb series and 100Mb series, both with optional port modules
Personal Hubs     , 100Mb
100Mb 4-port with up-link, 6-port with one switched 10/100Mb
Personal Hubs, 10Mb series
8-port + AUI, stackable to 5 high, + optional BNC of fiber port
8 or 9-port and 4 or 5-Port Personal Hubs, w/ man. up-link sw.
Media Converters, 10Mb and 100Mb series
All media combinations, incl. fiber ST, SC, mm., single mode
The “X-line” of configurable Mi X ed Media products:
Stackable Concentrators, SNMP optional, 13-Ports
Mini-Concentrators, 7 Ports, Repeaters, 2-Ports
Repeater Port Modules (RPMs), 6 types for Ethernet media
Bridge Port Modules (BPMs), 4 types, for segment isolation
Workgroup Bridges, 10Mb series
Local segmentation for all media types
Fan-Outs, 10Mb series
2, 4 and 8 Port Models
Transceivers, 10Mb and 100Mb series
10Mb Mini-Transceivers and Coax Models, All Types
100Mb MII-TX and MII-FX models
May. ‘98
