Grizzly 60" WORKBENCH H7724 - Manual (Page 5)

model h7724 (mfg. since 7/08)
-5-
parts Breakdown and List
parts
fastener Kit Item part Numbers (See figure 2).
ph7724006 BArrEL BoLt 3 1 ⁄
2
"
ph7724008 BArrEL nut
pW07 FLAt WAshEr 5 ⁄
16
"
pAW05m hEX WrEnCh 5mm
ph7724012 Wood sCrEW 2"
pW06 FLAt WAshEr 1 ⁄
4
"
pAW04m hEX WrEnCh 4mm
ph7724009 puLL KnoB
ps25 phLp hd sCr 8-32 X 5 ⁄
5
"
ph7724005 spECiAL CAp sCrEW 2"
ph7724025 CottEr pin
ph7724026 BEnCh dog
REf paRT DESCRIpTION
ph7724002-2 LArgE right pAnEL
ph7724001 CornEr BrACKEt Assy.
REf paRT DESCRIpTION
ph7724015 tABLE top
ph7724016 right sidE LEg
ph7724018 BACK Cross BrACE
ph7724017 LEFt sidE LEg
ph7724019 CEntEr pAnEL
ph7724020 mAin Bottom pAnEL
ph7724021 Front Cross BrACE
ph7724022 VisE AssEmBLy
ph7724014-3 smALL Front pAnEL
ph7724014-4 smALL BACK pAnEL
ph7724014-1 smALL LEFt pAnEL
ph7724014-2 smALL right pAnEL
ph7724030 drAWEr Bottom pAnEL
ph7724002-3 LArgE Front pAnEL
ph7724002-4 LArgE BACK pAnEL
ph7724002-1 LArgE LEFt pAnEL
Lr
ss
W1
W2
W3
W4
X1
X2
X3
y1
y2
z1
z3
z4
A
B
C
d
F
g
i
J
sB
sL
sr
Bp
LF
sF
LB
LL
