Grizzly 60" WORKBENCH H7724 User Manual
Instructions, Features, Assembly
MODEL H7724
60" WORKBENCH
INSTRUCTIONS
Copyright © ApriL 2009 By grizzLy industriAL, inC. rEVisEd dECEmBEr, 2011 (st)
WaRNINg: NO pORTION Of THIS MaNUaL May BE REpRODUCED IN aNy SHapE
OR fORM WITHOUT THE WRITTEN appROvaL Of gRIzzLy INDUSTRIaL, INC.
(For modELs mAnuFACturEd sinCE 12/11) #Cr11708 printEd in ChinA
figure 1. model h7724 Birch Workbench.
features
•
Lacquer-sealed birch wood surfaces.
•
Four 19
1
⁄
4
"W x 14"d x 2
1
⁄
4
"h ball-bearing slide
drawers.
•
two 19
1
⁄
4
"W x 14"d x 4
1
⁄
4
"h ball-bearing slide
drawers.
•
two 21
1
⁄
4
"W x 14
3
⁄
4
"d x 12
1
⁄
2
"h storage cabi-
nets.
•
Birch-faced vise with removable top plate and
6
3
⁄
4
" leadscrew travel, 12
1
⁄
2
" wide x 2
3
⁄
4
" thick.
•
Four chrome bench dogs.
•
overall dimensions: 66
1
⁄
2
" wide x 20" in depth
x 34" tall.
•
shipping weight: 148 lbs.
assembly
use the steps and figures below and refer to the
labels on the workbench parts to properly assem-
ble your workbench.
Tools Needed
Qty
phillips screwdriver #2 ...................................... 1
hex Wrench 4mm (included) ............................. 1
hex Wrench 5mm (included) ............................. 1
To assemble your workbench:
1. place the table (A) face down on the left over
shipping cardboard to avoid scratching the
workbench top.
figure 2. Fastener kit inventory.
Note: Refer to Page 4 for kit item part numbers.
Inventory
use the parts breakdown and listing in
figure 2
and on
page 4 to arrange your workbench parts
and inventory your shipment.
if any nonproprietary parts are missing (e.g. a
bolt or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Safety & Limitations
•
maximum workbench table load is 500 lbs.
•
do not stand or climb on the workbench.
•
do not apply an unbalanced load on the table
that could result in workbench tipping over.
•
Keep children away from the workbench.
•
do not use workbench outdoors or in wet or
damp locations.
•
do not overload the dogs or vise.
