W i r e l e s s E x i t S e n s o r
To use or not to use the Included Receiver
Depending on the type of control board you are using you may or may not need to use the RB709U-NB
universal receiver included with the Wireless Exit Sensor.
• Post mount operators with a GEN-3 Blue Control Board DO NOT
require that you use the RB709U-NB universal receiver.
(See the pictures below to determine if you have a GEN-3 Blue Control Board).
• ALL PAD MOUNT OPERATORS will require the use of the
RB709U-NB universal receiver.
1
2
3
4
O
N
D
IP
STATUS
LEARN RMT
LEARN
MAST LIMIT
LEARN
SLV LIMIT
S3
S4
S2
OFF
SOFT START OFF
WARNING OFF
OPEN PULL
SLV OPEN DLY.
MODE1 OFF
MODE2 OFF ON
ON
PUSH
SIMULT.
ON
ON
120 MIN MAX
AUTO CLOSE TIME STALL FORCE
GEN-3 Blue Control Board
DOES NOT require the RB709U-NB universal receiver
RB709U-NB
Universal Receiver
