Switch descriptions
www.gateway.com
Gateway 7201-24.2 fast Ethernet/gigabit Ethernet switch
Gateway 7401-05 (shown) and 7401-08 gigabit Ethernet switches
Speed LEDs
Link/Act
LEDs
Power
LED
Ports 1-8 Ports 9-16
Fast Ethernet
Ports 17-24
Port 25 and LEDs
Port 26 and LEDs
Gigabit Ethernet
Speed LEDs
Link/Act
LEDs
Power
LED
Ports 1-5
Gigabit Ethernet
Duplex LEDs
