Safety instructions
NOTE: In the event of leaks in the water pipework close the
main cold water stop valve. This is often located under a
kitchen sink.
IMPORTANT: A thermostatic mixing valve must be fitted to
the outlet of the cylinder and can be adjusted to the desired
domestic hot water temperature by an installation or service
engineer. Otherwise there is a risk of scalding as the cylinder
outlet temperature at the taps could be up to 85°C.
IMPORTANT: Risk of damage! Do not remove or modify any
components of the solar cylinder.
In the unlikely event of a malfunction occurring of the Flurocyl,
such as hot water flowing out of the temperature and pressure
relief valve, switch off the boiler and the immersion heater and
contact Glow-worm or your installer.
Safety Instructions
Unit Flurocyl 200 l Flurocyl 250 l Flurocyl 300 l
Cylinder:
Size
l 00 50 300
Maximum water supply pressure bar 0
Operating pressure bar 3.5
Pressure limiting valve bar 3.5
Expansion relief valve bar 6.0
Hot water expansion vessel admission pressure bar 4.0
Temperature and pressure relief valve °C/bar 95 / 7.0
Net weight kg 39 44 49
Weight (full) kg 45 30 340
Height mm 499 789 09
Cylinder connections:
Cold water supply
mm pressure pipe
Hot water connection mm pressure pipe
Pressure-controlled cold water outlet mm pressure pipe
Secondary return Inches G 3/4
Flow (boiler/solar circuit) mm pressure pipe
Return (boiler/solar circuit) mm pressure pipe
Electrical connections:
3 kW immersion heater (according to ENBS 60335)
30/40 V, 50 Hz
Length of the immersion heater mm 430
Motorised port valve 30/40 V, 50 Hz
Cylinder thermostat 30/40 V, 50 Hz
Thermal cut out for solar pump 30/40 V, 50 Hz
Heating coil:
Heat loss
kW/4 h .9 . .4
Heat up time (boiler part) mins 6 30
Recovery (boiler part) mins 3 6
Table . Technical data
Frost protection of the twin coil solar cylinder
You must drain the solar cylinder completely if it is to be shut
down in a room prone to frost. It is drained at the cold water
inlet with a T-piece with tap to be provided by the installer.
Also drain all heat exchangers which are not filled with solar
fluid.
