Section 8 — Exploded Views and Parts Lists
Air-cooled Generators
10kW, GT-530 Engine – Drawing No. 0F9429-N - Part 1
ITEM PART
NO. QTY. DESCRIPTION
1
0E9428B
1
CRANKCASE
2
0E3812
2
SEAL D 35 X 48.2
3
0C8566
2
SCREW HHFC M6 – 1.0 X 20
4
0E9367A
1
ASSY,
BREATHER
5
0E9366
1
GASKET BREATHER ASSY
6
0E9304
1
CYLINDER HEAD 1
7
0E9334C
1
COVER, ROCKER PLAIN
8
076390
4
PISTON PIN RETAINER RING
9
076389
2
PISTON
PIN
10
088057
2
PISTON
11
088411
2
PISTON RING SET
12
0E9322A
2
ASSY CONNECTING ROD
13
0E9407A
1
ASSY, CAM & GEAR
14
0E9350
1
GASKET CRANKCASE
15
0E9318E
1
ASSY CRANKSHAFT W/PLUG
16
043116
3
SCREW HHC M6 – 1.0 X 12
17
093873
3
WASHER LOCK M6 RIBBED
18
0G0272
1
ASSY GEROTOR
19
0E9482
1
SPRING OIL PRESSURE RELIEF
20
0A5776
1
BALL 11/32 DIA PRESSURE RELIEF
21
0C5315A
1
GEROTOR OUTER 9MM THICK
22
0C5314A
1
GEROTOR INNER 9MM THICK
23
0E9473
1
GEAR COVER
24
073144
9
SCREW HHFC M8 – 1.25 X 45
25
0C3027
2
O-RING 3/8 X 1/2
26
0E9358
1
SCREEN OIL PICK-UP
27
093064
1
ASSY, OIL FILL CAP
28
0E9334A
1
COVER, ROCKER, W/ FILL
29
0E9352
2
GASKET, VALVE COVER
30
0C3592
8
KEEPER, VALVE SPRING
31
0C3733
4
VALVE RETAINER
32
0C4390
4
SPRING VALVE
33
088156
2
SEAL, VALVE STEM
34
084186
4
WASHER, VALVE SPRING
35
0E9368
2
SPARKPLUG
36
077168
12
SCREW HHC M8 – 1.25 X 56
37
0E9305
1
CYLINDER HEAD 2
38
0C3590
2
VALVE EXHAUST
39
0E9351
2
GASKET CYLINDER HEAD
40
0C3591
2
VALVE INTAKE
41
083235
4
TAPPET, SOLID
42
0E9455E
4
PUSHROD, ALUMINUM
43
0E9353A
2
PLATE, PUSH ROD GUIDE
44
076307
4
NUT JAM (ROCKER ARM)
45
077160
4
ROCKER ARM
46
077161
4
STUD ROCKER ARM PIVOT
47
0G0273
1
GASKET KIT
48
0G0274
1
BREATHER KIT
49
0G0275
1
KIT HEAD ASSY CYLINDER #1
50
0G0276
1
KIT HEAD ASSEMBLY CYLINDER #2
51
0E9502
1
SEPERATOR, OIL, GT530
52
080318
12
SCREW HHFC M6 – 1.0 X 25
53
0E3372C
1
SEPARATOR, OIL BREATHER GT530
54
078699B
6
SLEEVE DOWEL PIN 12 DIA.
55
0C5943
1
SEAL, OIL PASSAGE
56
043790
1
BARBED EL 90 3/8 NPT X 3/8
