Support Information
M9328MX21ADSE User’s Manual, Rev. A
Freescale Semiconductor
3-29
Figure 3-17. Connectors PE1, PE2, and PE3 Pin Numbering
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
C
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
B
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
A
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Table 3-17. Image Sensor Connector PE1 Signal Description
Pin(s)
Signal
Description
A1,B1,C1
GND
GROUND
A2
CSI_D0
CMOS SENSOR INTERFACE DATA 0— Image Sensor input data
A3
CSI_D2
CMOS SENSOR INTERFACE DATA 2— Image Sensor input data
A4
CSI_D4
CMOS SENSOR INTERFACE DATA 4— Image Sensor input data
A5
CSI_D6
CMOS SENSOR INTERFACE DATA 6— Image Sensor input data
A6
CSI_PIXCLK CMOS SENSOR INTERFACE PIXAL CLOCK — Data latch strobe
A7
CSI_VSYNC CMOS SENSOR INTERFACE VERTICAL SYNC — Control input
A8
I2C_CLK
I SQUARED C CLOCK — Serial clock, bidirectional
A9
CSPI2_SS1
SLAVE SELECT 1 — CSPI signal (bidirectional)
A10
CSPI2_SS2
SLAVE SELECT 2 — CSPI signal (bidirectional)
A11-A15
NC
NO CONNECTION
A16,B16,C16
VCC
+3 VDC power
B2-B15
NC
NO CONNECTION
C2
CSI_D1
CMOS SENSOR INTERFACE DATA 1— Image Sensor input data
C3
CSI_D3
CMOS SENSOR INTERFACE DATA 3— Image Sensor input data
C4
CSI_D5
CMOS SENSOR INTERFACE DATA 5— Image Sensor input data
C5
CSI_D7
CMOS SENSOR INTERFACE DATA 7— Image Sensor input data
C6
CSI_HSYNC CMOS SENSOR INTERFACE HORIZONTAL SYNC— Control input
C7
CSI_MCLK
CMOS SENSOR INTERFACE MASTER CLOCK — Clock output to the sensor card
C8
I2C_DAT
I SQUARED C DATA — Serial data, bidirectional
C9
NC
NO CONNECTION
C10
CSI_CTL0
CMOS SENSOR CONTORL 0 — Control output from MM I/O
C11
CSI_CTL1
CMOS SENSOR CONTORL 1 — Control output from MM I/O
C12
CSI_CTL2
CMOS SENSOR CONTORL 2 — Control output from MM I/O
C13-C15
NC
NO CONNECTION
