B_A3

BUFFERED ADDRESS 3 — Buffered address output

B_D7

BUFFERED DATA 7— Buffered bidirectional data bus bit

B_D15

BUFFERED DATA 15 — Buffered bidirectional data bus bit

B_D6

BUFFERED DATA 6 — Buffered bidirectional data bus bit

100

B_D14

BUFFERED DATA 14 — Buffered bidirectional data bus bit

101

B_D5

BUFFERED DATA 5— Buffered bidirectional data bus bit

102

B_D13

BUFFERED DATA 13 — Buffered bidirectional data bus bit

103

B_D4

BUFFERED DATA 4 — Buffered bidirectional data bus bit

104

B_D12

BUFFERED DATA 12 — Buffered bidirectional data bus bit

105

B_D3

BUFFERED DATA 3 — Buffered bidirectional data bus bit

106

B_D11

BUFFERED DATA 11 — Buffered bidirectional data bus bit

107

B_D2

BUFFERED DATA 2 — Buffered bidirectional data bus bit

108

B_D10

BUFFERED DATA 10— Buffered bidirectional data bus bit

109

B_D1

BUFFERED DATA 1 — Buffered bidirectional data bus bit

110

B_D9

BUFFERED DATA 9— Buffered bidirectional data bus bit

111

B_D0

BUFFERED DATA 0— Buffered bidirectional data bus bit

112

B_D8

BUFFERED DATA 8— Buffered bidirectional data bus bit

113

B_A20

BUFFERED ADDRESS 20 — Buffered address output (Reserved)

114

B_A21

BUFFERED ADDRESS 21 — Buffered address output

115

B_A22

BUFFERED ADDRESS 22 — Buffered address output

116

B_A23

BUFFERED ADDRESS 23 — Buffered address output

117

B_A24

BUFFERED ADDRESS 24 — Buffered address output (Reserved)

118

B_A25

BUFFERED ADDRESS 25 — Buffered address output (Reserved)

119

TP25

Test point

Table 3-1. CPU to Base Board PX1/PY1 Connector Signals (continued)

Pin(s)

Signal

Description
