M9328MX21ADSE User’s Manual, Rev. A
Freescale Semiconductor 3-5
66 UART1_TXD UART1 TRANSMITTED DATA — Serial output signal
67 UART2_RTS UART2 REQUEST TO SEND — Active low input signal
68 UART2_CTS UART2 CLEAR TO SEND — Active low output signal
69 UART2_RXD UART2 RECEIVED DATA — Serial input signal
70 UART2_TXD UART2 TRANSMITTED DATA — Serial output signal
71 BOOT3 BOOT location select input bit 3
72 BOOT2 BOOT location select input bit 2
73 BOOT1 BOOT location select input bit 1
74 BOOT0 BOOT location select input bit 0
75 PWM0 PULSE WIDTH MODULATOR OUTPUT
76 TIN TIMER INPUT CAPTURE — Timer input
77 JTAG_CTRL JTAG CONTROL — input to select between and ARM and normal JTAG operation
78 TOUT TIMER OUTPUT
79 RESET_IN_B RESET IN — Active low reset signal to the processor
80 RESET_OUT_B RESET OUT — Active low reset signal from the processor
81 POR_B POWER ON RESET
82 RTCK_GPIO RETURN CLOCK — JTAG signal, can be general purpose I/O
83 CLKMODE0 CLOCK MODE BIT 0 — Selects PLL bypass modes
84 CLKMODE1 CLOCK MODE BIT 1 — Selects PLL bypass modes
85 B_CS5_B BUFFERED CHIP SELECTS 5 — Chip select signal, active low output (Reserved)
86 B_CS4_B BUFFERED CHIP SELECTS 4 — Chip select signal, active low output (Reserved)
87 B_CS1_B BUFFERED CHIP SELECTS 1 — Chip select signal, active low output
88 B_CS0_B BUFFERED CHIP SELECTS 0 — Chip select signal, active low output (Reserved)
89 B_OE_B
BUFFERED OUTPUT ENABLE— Enables external devices to drive the data bus,
active low output
90 B_RW_B
BUFFERED READ/WRITE — A low indicates an external write operation, a high indicates
a read operation type
91 B_NEXUSEVTI Internal use only
92 NEXUS_EN_B Internal use only
93 B_A0 BUFFERED ADDRESS 0— Buffered address output (Reserved)
94 B_A1 BUFFERED ADDRESS 1— Buffered address output
95 B_A2 BUFFERED ADDRESS 2 — Buffered address output
Table 3-1. CPU to Base Board PX1/PY1 Connector Signals (continued)
Pin(s) Signal Description
