3 how to connect with a pc – Furuno 1734C User Manual
Page 28
20
2.3 How to Connect with a PC
When connecting with the personal computer, prepare the optional cable assy
MJ-A7SPF0007-050C and D-sub 9 pins plug (local supply), and connected them as follows.
This function is not available with the GD-1720C.
SHIELD
BLUE
D-SUB 9PIN
MJ-A7SPF0007-050C
1
5
6
9
WHITE
BLUE
CD
RD
TD
DTR
GND
DSR
RTS
CTS
RI
1
2
3
4
5
6
7
8
9
TD
RD
RD_A
RD_B
+12V
EXT BUZZ
GND
1
2
3
4
5
6
7
SHIELD
short
WHITE
MJ-A7SPF0007-050C cable connection for PC
