Furuno 1734C User Manual
Page 16
8
Rubber gasket
Gasket
Cable Gland
Sectional view
Mounting base
Rubber gasket
Antenna unit, inside view
8. Referring to the figure shown below, fasten the shield cable with screw (M4x10) on the
chassis to ground the unit.
Connect 10 pin
connector
here (J811).
Connect
shield cable
here.
Connect 9 pin
connector
here (J801).
How to connect the antenna cable to the antenna unit
